Tortilla Production Line Machine CPE-400

Machine Specification:

Size  (L)6500mm * (W)1370mm * (H)1075mm
Electricity  3 Phase ,380V,50Hz,18kW
Capacity  900(pcs/hr)
Model No. CPE-400
Press size 40*40cm
Oven Three level/Layer Tunnel Oven
Application Tortilla, Roti, Chapati

Flour tortillas have been produced for centuries and have become popular around the globe. Traditionally, tortillas have been consumed on the day of baking. However, the need for high capacity tortilla production line has therefore increased . We have transformed the traditions of the past into a state-of-the-art production line. Most tortillas are now manufactured by hot press. The development of Flatbread Sheeting lines is one of the core expertise’s of ChenPin. Hot-press tortillas are smoother in surface texture and more elastic and rollable than other tortillas.

For More details picture please click on detailed photos.

  • Previous:
  • Next:

  • 1. Dough ball chopper
    ■ Mixed dough of tortilla, chapati, Roti is placed on the feeding hopper
    ■ Material: Stainless Steel 304
    ■ Dough ball are chopped according to desire weight of tortilla, roti, chapati

    1.Dough ball chopper

    Photo Of Tortilla Dough ball chopper

    2. Tortilla Hot press machine
    ■ Easy to control the temperature, pressing time and diameter of tortilla, roti, chapati through control panel.
    ■ Size of pressing plate: 40*40cm
    ■ Hot press system: Presses 1 pieces of all size products at a time as the press size is 40*40cm. The average production capacity is 900 pcs/hr. Hence, This production line is suitable for small scale industries.
    ■ All size of tortilla,roti,chapati adjustable.
    ■ Independent temperature controls for both top and bottom hot plates
    ■ Hot press technology give enhance the rollability property of tortilla.
    ■ It is also known as single row press. Pressing time is adjustable through control panel

    2.Tortilla Hot press machine

    Photo of Tortilla Hot Press Machine

    3. Three level/ Layer Tunnel Oven
    ■ Independent control of burners and top/bottom baking temperature. After turning on, the burners are automatically controlled by temperature sensors to ensure constant temperature.
    ■ Flame failure alarm: Flame failure can be detected.
    ■ Size: 3.3 meter long oven and 3 level
    ■ It have independent temperature controls. 18 Igniter and ignition bar.
    ■ Independent burner flame adjustment and volume of gas.
    ■ It is also known as automatic or smart oven due to ability to maintenance temperature at the parameter of degree set.

    3.Three level Layer Tunnel Oven

    Photo of Tortilla Three level tunnel oven
