CPE-788H Paratha pressing and filming machine
CPE-788H Paratha pressing and filming machine
| Size | (L)4,200mm * (W)1,100mm * (H)1,350mm(L)5,630mm * (W)1,480mm * (H)1,360mm |
| Electricity | 1Ph,220V,50/60Hz,1kW |
| Application | Scallion Paratha,Meat pie,Tongguang flatbread,Lacha paratha,Pastry |
| Capacity | 5,000-6,000(pcs/hr) |
| Diameter | 120-225（mm） |
| Model No | CPE-788H Square film /4Rows
CPE-788HG Square film /4Rows
|
Dough ball conveying
Here dough ball is placed between two filming roller.
It has location guide to feed dough ball on work bench. Emergency stop on provide beside the feeding dough ball work station.
4 rows of conveyor to maximize capacity.
Pressing and filming process
These two film roller is used for filming paratha skin. Lower roller films lower surface and upper roller films upper surface of paratha skin after being pressed.
Control Panel
From here you can adjust product deliver time molding plate time and Product counter
Cutting and counter stacking
After completion filming and pressing. Film is now cut into square shapes. After cutting film then automatically starts counter stacking into conveyor belt.
It has safety gate to prevent from cutter.
Pressing mould makes perfect round paratha.
This press is versatile can be used to press any kind of frozen flat bread.
CPE-788H/CPE-788HG is for the pressing and filming of dough ball. We have several model for paratha dough ball production line like: CPE-3268, CPE-3368, CPE-3000L, CPE-3168. Each model has been designed according the making process of paratha to meet your demand. All production lines are automatic easy to operate. Contact us and we can recommend the best model suitable for you.
