Puff Pastry Sheet Production Line Machine CPE-3000N+CPE-3140
CPE-3000N+3140 Automatic Puff Pastry Sheet Production Line
| Size | 14,415(L)*7,500(W)*2,260(H)mm |
| Electricity | 380V , 3Ph , 50/60Hz , 26kW |
| Application | Puff pastry sheet |
| Capacity | 300-600kg/hr |
| Model No. | CPE-3000N |
Pastries are increasingly popular at the breakfast table or as an in-between snack. In any shape or size, pure or filled with the finest chocolate or preserves, all pastries and laminated products can be shaped by the CPE-3000M line developed by ChenPin. This production line will allow you to form and shape dough (mostly laminated dough) into high-quality puff pastries,croissant and egg tart , just the way you want it in large quantities (for midsize to industrial bakeries) and with a superb product quality. The ChenPin Puff Pastry line can handle a large variety of dough types with a broad range of shapes and sizes.
Dough pieces for a wide range of confectionery products for both baking and preparation of frozen semi-finished products are formed out of the dough produced on the line.
| Size | 1,670(L)*900(W)*1,610(H)mm |
| Electricity | 220V , 3Ph , 50/60Hz , 3kW |
| Application | Puff pastry sheet |
| Capacity | 4,800-7,200pcs/hr |
| Model No. | CPE-3140 |
Puff Pastry Sheet
Egg Tart
Wuren pastry
Palmier
Crispy Durian Pastry
1. Filling/Wrapping for puff pastry
■ Automatic Margarine extrusion and wrap it inside dough sheet.
■ Fine thickness are achieve through dough sheeters and side through calibrator. Wastage are collected to hopper.
■ Material of is made of stainless steel 304.
2. Multilevel layering
■ Transverse dough laying units (laminators) with roller spreaders, the development of which allowed to simplify the process of laying the dough ribbon, to provide a wider range of adjustment of the number of layers and more convenient access to the structural elements.
■ This process is repeated twice resulting several layers.
■ As the production line is automatic it is easy to handle and clean.
3. Close View of layers
■ Result of twice layer through Transverse dough laying units result in several layers. You can have a close view of dough produced by ChenPin technology.
■ This line produce dough laminator which can be use to mould into several products like croissant , puff pastry, Egg tart,Layered paratha,etc and may more dough related multi level/layer pastries.
